| Material: | Electro galvanized wire |
| Feature: | High tensile strength |
| Application: | Industry, agriculture, construction |
- Welcome to Hebei Ouan Trading Co., Ltd
Weld Mesh
Weld Mesh
Welded wire mesh is used in Industry and Agriculture Building, Transportation and Mining for all such purposes as Poultry Houses, Egg Baskets, Runway Enclosures, Draining Rack, Fruit Drying screen, Fences, etc.
Hot Dipped Galvanzied Welded Wire Mesh
Hot Dipped Glavanized Welded Wire Mesh Fence
Hot Dipped Welded Wire Mesh
Welded Mesh
Opening: 1/4"x1/4" to 6"x6"
Wire diameter: 0.45mm-4.5mm
Width: 1m, 1.22m, 1.524m, 1.82m, 2.0m etc. custom require available at request.
Roll length: 15m, 30m, 50m etc. custom require available at request.
Material:
Electro galvanized wire, hot-dipped galvanized.
We choose the best low carbon wire or stainless steel wire material available in China.
The high quality & reasonable price product is from the right material.
Welding type:
Electro galvanized before welding wire mesh
Electro galvanized after welding wire mesh
Hot-dipped galvanized before welding wire mesh
Hot-dipped galvanized after welding wire mesh
Iron/galvanized wire + PVC coated
Stainless steel 304,316 wire
| Specification List of Welded Wire Mesh | ||
| Opening | Wire diameter | Width |
| 1/4" x 1/4" | 0.5mm-0.7mm | 300mm-1828mm |
| 3/4" x 3/4" | 0.7mm-2.0mm | 300mm-1828mm |
| 3/8" x 3/8" | 0.7mm-1.1mm | 300mm-1828mm |
| 5/8" x 5/8" | 0.8mm-1.2mm | 300mm-1828mm |
| 1/2" x 1/2" | 0.45mm-1.6 mm | 300mm-1828mm |
| 1" x 1" | 0.7mm-3.0mm | 300mm-2000mm |
| 1" x 1/2" | 0.8mm-1.6mm | 300mm-1828mm |
| 1-1/2" x 1-1/2" | 0.7mm-3.5mm | 300mm-1828mm |
| 1" x 2" | 1.6mm-2.1mm | 300mm-1828mm |
| 2" x 2" | 0.7mm-4.0mm | 300mm-2500mm |
| 2" x 3" | 1.5mm-3.5mm | 300mm-2000mm |
| 2" x 4" | 2.0mm-4.0mm | 300mm-1828mm |
| 3" x 3" | 1.0mm-4.5mm | 300mm-2500mm |
| 3" x 4" | 1.5mm-4.5mm | 300mm-2000mm |
| 4" x 4" | 1.0mm-4.5mm | 300mm-2500mm |
| 5" x 5" | 2.5mm-4.5mm | 300mm-2500mm |
| 6" x 6" | 2.5mm-4.5mm | 300mm-2500mm |
| Technical Note: 1,Standard roll length:15.24m,30m,50m 2,Special sizes available at request 3,Packing: in waterproof paper in rolls. Custom packing available at request. | ||
| Specification List of Welded Wire Mesh | ||
| Opening | Wire Diameter<BWG> | |
| In inch | In metric unit(mm) | |
| 1/4" x 1/4" | 6.4mm x 6.4mm | 22,23,24 |
| 3/8" x 3/8" | 10.6mm x 10.6mm | 19,20,21,22 |
| 1/2" x 1/2" | 12.7mm x 12.7mm | 16,17,18,19,20,21,22,23 |
| 5/8" x 5/8" | 16mm x 16mm | 18,19,20,21, |
| 3/4" x 3/4" | 19.1mm x 19.1mm | 16,17,18,19,20,21 |
| 1" x 1/2" | 25.4mm x 12.7mm | 16,17,18,19,20,21 |
| 1-1/2" x 1-1/2" | 38mm x 38mm | 14,15,16,17,18,19 |
| 1" x 2" | 25.4mm x 50.8mm | 14,15,16 |
| 2" x 2" | 50.8mm x 50.8mm | 12,13,14,15,16 |
| Technical Note: 1.Standard roll length: 30m;width: 0.5m to 1.8m 2.Special sizes available at request 3.Packing: in waterproof paper in rolls. Custom packing available at request. | ||
